Heat Exchanger Brazed Plate - Non Insulated. GEA
Product code:
GBS100M-14
| Product Group : | Braze Plate Heat Exchangers |
|---|
General Information
| Number Of Plates : | 14 |
|---|---|
| Product Group : | Braze Plate Heat Exchangers |
Capacity
| Capacity : | 4.0 kW Condensing kW |
|---|
Connections
| Connection Size : | 5/8 in F.SW and 3/4 in BSP |
|---|
Material
| Body Material : | Stainless Steel |
|---|---|
| Connection Material : | Stainless Steel |
| Plate Material : | Stainless Steel |
Measurements
| Depth : | 40 mm |
|---|---|
| Height : | 204 mm |
| Weight : | 1.4 kg |
| Width : | 74 mm |
Pressure
| Max Operating Pressure : | 31 Bar |
|---|
14 Plate uninsulated Brazed Plated Exchanger , stainless steel plates copper brazed. Suitable for water, oil, glycol and refrigerants
| File name | Document Type | Extension | Size |
|---|---|---|---|
| 230901-manual-kelvion-de-en-fr-ast-4014028.pdf | Installation Manual | 720.73 KB | |
| gbs100m-1910-en-rev-b-ast-4014029.pdf | Plan 2D/3D View | 144.77 KB |
