Pressure control valve, KDC 65 A 2
Danfoss
Product code:
148G3588
| Product Group : | Multifunctional Compressor Valves |
|---|
General Information
| Product Group : | Multifunctional Compressor Valves |
|---|---|
| Type : | KDC 65 A 2 |
Compressor
| PED Category : | II |
|---|
Connections
| Connection Standard : | ASME B 36.10M SCHEDULE 40 |
|---|---|
| Connection Type : | Butt weld |
Logistical Information
| Commodity Code : | 84818099 |
|---|---|
| Country Of Origin : | CHN |
| EAN : | 5702428279741 |
| Gross Weight : | 5.682 kg |
| Packaging Height : | 115 mm |
| Packaging Length : | 280 mm |
| Packaging Width : | 195 mm |
Pressure
| Max Operating Pressure : | 40.0 Bar |
|---|
Refrigerant
| Refrigerant : | R22, R134a, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R409A, R410A, R421A, R502, R507A, R717, R744 |
|---|
Standards
| Approval : | CE, UKCA |
|---|
Valves
| Direction : | Angleway |
|---|---|
| Fluid Group : | 1 |
