Solenoid valve, EVRS 3
Danfoss
Product code:
032F3080
Product Group : | Solenoid Valves |
---|
General Information
Function : | NC |
---|---|
Product Group : | Solenoid Valves |
Type : | EVRS 3 |
Additional Info
Family : | EVRS |
---|
Connections
Inlet Connection Size : | 3/8 in |
---|---|
Inlet Type : | Butt weld |
Outlet Connection Size : | 3/8 in |
Outlet Type : | Butt weld |
Kv Values
Kv Value : | 0.230 m³/h |
---|
Logistical Information
Commodity Code : | 84818079 |
---|---|
Country Of Origin : | POL |
EAN : | 5702422038368 |
Gross Weight : | 0.352 kg |
Material
Body Material : | Stainless Steel |
---|---|
Connection Material : | Stainless Steel |
Measurements
Weight : | 0.30 kg |
---|
Pressure
Max OPD, 10W AC : | 21 Bar |
---|---|
Max OPD, 12W AC : | 25 Bar |
Max OPD, 20W AC : | 14 Bar |
Max Operating Pressure : | 50.0 Bar |
Min OPD : | 0.000 Bar |
Refrigerant
Refrigerant : | R22, R134a, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R409A, R410A, R421A, R502, R507A, R717, R744 |
---|
Standards
Approval : | EAC, LLC CDC TYSK |
---|
Temperature
Ambient Temperature Range : | -40-80 °C |
---|---|
Medium Temperature Range : | -40-105 °C |
Medium Temperature Range Note : | Defrost max 130°C/265°F |
Valves
Actuator Size : | 13.5 mm |
---|---|
CV Value : | 0.270 gal/min |
Coil : | No |
Direction : | Straightway |
Flow Direction Indicator : | Embossed 1-way arrow |
Orifice Size : | 2.60 mm |
Valve Operation : | Direct-operated |
EVRS Valve 3.0 Weld con. 3/8in Multi 16
