Reciprocating compressor, MTZ22JC5VE
Danfoss
Product code:
MTZ22-5VI
| Product Group : | Reciprocating |
|---|
General Information
| Colour : | Blue |
|---|---|
| Cooling Type : | Suction |
| Model Number : | MTZ22JC5VE |
| Number Of Cylinders : | 1 |
| Product Group : | Reciprocating |
| Type : | MTZ |
Application
| Application : | H/MBP/AC |
|---|
Capacity
| Capacity Control : | Fixed speed |
|---|
Capacity HBP
| Capacity HBP -5°C : | 3695 kW |
|---|---|
| Capacity HBP -5°C R448A : | 3695 W |
Compressor
| Displacement : | 38.12 cm³ |
|---|---|
| Power Supply Compressor : | 220-240/1/50 V/Ph/Hz |
| Swept Volume : | 38.12 cm³ |
| Technique : | Hubkolben |
Connections
| Connection Type : | Valve/Rotolock |
|---|---|
| Discharge Connection Height : | 68 mm |
| Discharge Connection Pipe Size : | 3/8 in |
| Discharge Line Connection Size : | 1 in |
| Suction Connection Height : | 263 mm |
| Suction Connection Pipe Size : | 1/2 in |
| Suction Line Connection Size : | 1 in |
Electrical
| Capacity Of Capacitor A : | 20 µF |
|---|---|
| Capacity Of Capacitor B : | 100 µF |
| Capacity Of Capacitor C : | 10 µF |
| Frequency : | 50 Hz |
| IP Class : | IP55 |
| LRA : | 41 A |
| MCC : | 15 A |
| Power Supply : | 230/1/50 V/Ph/Hz |
| RLA : | 10.7 A |
| Voltage : | 220-240/1/50 V/Ph/Hz |
Logistical Information
| Commodity Code : | 84143081 |
|---|---|
| Country Of Origin : | FRA |
| EAN : | 5702428661607 |
| Gross Weight : | 24.88 kg |
Measurements
| Diameter : | 224 mm |
|---|---|
| Height : | 333 mm |
| Net Weight : | 23 kg |
Motor
| Motor Type : | PCS/CSR |
|---|
Oil
| Oil Charge : | 950 cm³ |
|---|---|
| Oil Equalization : | 3/8'' flare SAE |
| Oil Type : | 175PZ |
Performance
| Nominal HP : | 1.7/8 |
|---|
R404A Performances
| R404A Nominal Capacity -5°C : | 2270 W |
|---|
Refrigerant
| Max Refrigerant Charge : | 2.50 kg |
|---|---|
| Refrigerant : | R134a, R404A, R407A, R407C, R407F, R448A, R449A, R452A, R507A, R513A |
Valves
| Expansion Device : | V |
|---|
MTZ022-5
| File name | Document Type | Extension | Size |
|---|---|---|---|
| installation-guide-danfoss-reciprocating-compressors-mt-mtz-ntz-vtz-ast-an23018649735402-000601.pdf | Installation Manual | 4.6 MB | |
| eu-declaration-of-conformity-8555013-ak-lvd-ped-pressure-ast-id375130414995-0901.pdf | Conformity Declaration | 264.29 KB | |
| eu-danfoss-declaration-of-conformity--packaging---8555081aa-ast-id564733268562-0101.pdf | Conformity Declaration | 139.79 KB | |
| safety-data-sheet-polyolester-oil-175pz-english-13-04-2022-ast-bh261646311103en-000202.pdf | Safety Data Sheet | 605.9 KB | |
| compressors-watch-out-for-counterfeits-to-protect-your-image-ast-ad170086418808en-020601.pdf | Brochures | 3.23 MB |
